Description
Buy Vortex Mass Flow Meter M23-VTP-SL-R online in Dubai which is engineered for precise multivariable measurements, including velocity, temperature, and pressure. Its insertion design with a remote NEMA 4X IP66-rated enclosure and 50 ft. cable ensures flexibility for challenging installations. Designed for extreme temperatures (-200°C to 260°C) and pressures up to 300 PSIa, it is a robust solution for industrial applications. Its digital display with programmable buttons simplifies operation, while the compression fittings ensure secure placement.
Key Features of Vortex Mass Flow Meter Insertion Type (Remote Version) (M23-VTP-SL-R):
- Multivariable Measurement: Tracks velocity, temperature, and pressure.
- Remote Operation: 50 ft. cable with IP66-rated remote enclosure.
- High Performance: Handles pressures up to 300 PSIa and extreme temperatures.
- Output Options: 4-20 mA, pulse, alarm, and HART for advanced integration.
- Durable Build: Compression fittings for 2-inch NPT connections.
- Probe Length: Standard Length
- Electronics Enclosure: Remote Enclosure NEMA 4X, IP66 Enclosure (50 Ft cable)
- Display Option: Digital Display and Programmable Buttons
- Input Power: 12-36 VDC, 25 mA, 1W Max, required on loop Powered Meters
- Output: Loop Powered Option, One analogue output (4-20 mAdc), One Alarm, One Pulse, hart,
- Temperature Option: Standard Temperature -200 to 260 Deg.C
- Pressure Option: Maximum: Process Pressure 300 PSIa, Proof Pressure 600 PSIA
- Process Connection: Compression Fittings 2 inch NPT
- Make: Vortek Instruments USA
